This is a double walled tray. This structure is a set-up with two parts, the upper is a little bigger than the lower part. Tray box is a basic box type fo folding carton.Features of packaging box design:1 The lip cover is on the main face, so the height is relatively small.2 Tray folding carton is make one board in the middle and fold at n angle.3 The corner is sealed or glued by lock.4 The structure is designed with an opening knife at the flap to facilitate the insertion of the partition structure without adhesive.5 This structure is glued by the joints.6 Can design lock, display window, handler, or reveal frame structure.7 The main characteristics of this kind of packaging box: double walled design can protect the products very well.Packaging design advantages and usages:1 After opening, the visible face is very large and can have a good display, have good effects on promotions. This structure is usually used for making shoe box.2 This packaging structure is the body extension that made the box lid. It is also called telescope-type carton,it is made of two seperate parts.3 This kind of structure is widely used in exhibition goods by supermarkets.4 It is suitable for hard loading products or high-piled products.Display box packaging design:in the field of retailers, display box(exhibition boxes) has become a more effective means for promotion. Modern retail shop is busy, most goods sales are chosen by the consumers themselves, without salespersons' selling.1 Should be tailored according to the consumers, to make a variety of display box packagings.2 General packaging materials as the corrugated carton.3 Display vending shelves put near the checkout counter.4 This packaging is usually used for small ornament packaging design, underwear packaging, tie packaging design.

This is a double walled tray. This structure is a set-up with two parts, the upper is a little bigger than the lower part. Tray box is a basic box type fo folding carton.Features of packaging box design:1 The lip cover is on the main face, so the height is relatively small.2 Tray folding carton is make one board in the middle and fold at n angle.3 The corner is sealed or glued by lock.4 This structure is glued by the joints.5 Can design lock, display window, handler, or reveal frame structure.6 The main characteristics of this kind of packaging box: double walled design can protect the products very well.Packaging design advantages and usages:1 After opening, the visible face is very large and can have a good display, have good effects on promotions. This structure is usually used for making shoe box.2 This packaging structure is the body extension that made the box lid. It is also called telescope-type carton,it is made of two seperate parts.3 This kind of structure is widely used in exhibition goods by supermarkets.4 It is suitable for hard loading products or high-piled products.Display box packaging design:in the field of retailers, display box(exhibition boxes) has become a more effective means for promotion. Modern retail shop is busy, most goods sales are chosen by the consumers themselves, without salespersons' selling.1 Should be tailored according to the consumers, to make a variety of display box packagings.2 General packaging materials as the corrugated carton.3 Display vending shelves put near the checkout counter.4 This packaging is usually used for small ornament packaging design, underwear packaging, tie packaging design.

This is a room-shaped pallet box with a side lock. The structure is generally assembled and is divided into two parts, which are slightly larger than below. Tray trays are a basic style of folding trays.Box design structure features:1 The lid is located on the folding tray on the largest box surface and the height will be relatively small.2 tray folding box is centered on one night cardboard, the surrounding cardboard is angled folded into the main box type.3 Corners are closed by locking, sticking or other means.Box design benefits and uses:1 After opening, observe the visual area of the interior, with good display effect, conducive to consumer selection and purchase, usually used as a gift box.2 This packaging structure is part of the combined structure (up or down), also known as the Sky box. It is made up of two separate structures, and the length and width of the lid is slightly larger than the box body.Special box design:1 Bright colors, excellent texture, beautiful picture.2 The packaging structure is usually changed in the traditional structure to make the shape special.3 The purpose of the special box packaging design is to sell surprise and imagination to consumers.4 Generally also used to pack objects of special shape.

This is the international standard corrugated carton box. 0427 type is a single sealing carton, without upper shake cover, joint sealing can adopt manual or automatic way.International standard corrugated carton has two kinds: one kind is approved by the International Association of Corrugated Board (International Corrugated Case Association, ICCA), made by the European Federation of Corrugated Carton Manufacturers and Europe Homogenous Board Organization (European Solid Board, Organization, ESBO), named International currugated box standards, contains relatively complete box types. Another kind is the own formulation of national standards by Japan and the United States. The international association of corrugated cardboard box text name (Description) using 4 ~ 8 digits code. The former two is box type, latter two is the serial number.In general, use the standard box type.However, different manufacturers may according to the need, do some improvements and produce a kind of new structure based on the standard type, with a suffix to annotate, 0201-2, for example, a retrofit type of 0201 carton.02 Box:It is the most common slotted carton (slotted -type boxes)1 Made by a corrugated paper board, both shake covers without independent separation, conjoined shake cover can seal carton.2 Generally, die cut box need to use a pin, glue or tape to joint.3 When using, need to hold out the billet, seal the upper and the lower shake covers, make the carton.4 Four carton forming ways: manual (M), automatic(A), manual or automatic(M/A), semi-automatic and manual (M + A).5 Because box billet can do folding during transportation, transportation cost is low. Because the corrugated wall along the height direction, with good ability against the high pressure.

This is a very common box type--- tube type box with reverse tuck. For this box template, there are three tuckstructures in the box template library of Packmage CAD, And dustflaps has two offset ways.Packaging structure design features:1 One board after folding, and glued the two opposite edges, can form one tube body.2 Opening on the upper and down sides for sealing end of the reverse tuck.3 Tuck structures: sloved the problem that the box can be self-opened. There are lock structures between tucks and dustflaps.Advantages and usages of this packaging structure:1 Tube type box must be convenient to let products in, and can not be opened easily. It must be protective.2 This packaging box structure usually used in the bottle packaging, for example: cosmetics packaging.Key points of cosmetic packaging design:1 Packaging should be colorful, has good texture with beautiful pictures.2 Cosmetic packaging is usually folding carton, but also has compose type structure.3 The purpose is to make consumers believe that they can be elegant, beautiful and acctractive.

This is overlapping seal end box, with lock structure top and snap lock bottom(or called Houghland). Formed by a corrugated paper board, without independent shake covers, but one piece upper and lower shake cover to seal the carton.Packaging design features:1 A piece of cardboard after folding, glue the edges and make a tube box.2 When using, need to hold out of the billet, sealing both shake covers, form cartons.3 Because billet can be folded during transportation, transportation cost is low.4 Due to curves along the height direction, so with good ability against high pressure.5 Big cover carton, added a layer at the top, cost more material consumption.6 With top lock design at the top, the carton can be used to store items.7 Bottom snap lock: also called bottom lock type packaging box.8 Can also add a handhold design, used as a gift box.9 Three tuck bottom: when the box is too long, need a third tuck to enhance the strength. The added tuck lengthh is 1/5 of the box.Gift packaging design.1 Gift boxes not only are just beautifu, but also should be exquiste and good for transportation.2 It is also conveinent for mannual glue.3 According to the goods' value, choose the right packaging materials.4 This packaging structure should be rational, beautiful. Attach more importance to the forms and textures.Key points of bottom lock structure:1 Bottom bear the weight of the goods, also affected by pressure, vibration, drop, etc.2 Design requires strength, simple design. Usually can use various faces with bolt combination locks, make strong sealing forming.3 This kind of bottom lock type packaging structure is simple, beautiful, and economic. There is certain strength and tightness, is the most common used packaging structure in packaging box with low cost. It is widely used in cosmetics, wine and food packaging design.4 Add a tuck when the box body is too long.

This is an overlap with pre-perforated spout, tissue box.Tissue box design features:1 A piece of cardboard after folding, glue the edges and make a tray box.2 When using, need to hold out of the billet, sealing both covers, formed a carton.3 Cardboard utilization is high, when sealing cover closed, without seam.4 On the primary side hollow out design, usually used for pumping paper tissue box.Tissue box packaging design.1 Healthy, comfortable, easy to use, suitable for home, office, hotel, or car using.2 Boxes with tissue structure, high-end, grade, paper soft with high quality.3 Design inspiration comes from observation of the society,candesign seriesofspring, summer, autumn and winter seasons as the theme .4 Design should be convenient for the product and box putting..

This is a hexagon, overlapping seal box. Formed by a piece of corrugated board, one piece upper and lower shake cover can seal the carton.Packaging design features:Main design characteristic of the packaging carton is the hexagonal design.1 A piece of cardboard after folding, glue the edges and make a tube box.2 When using, need to hold out of the billet, sealing both shake covers, form cartons.3 Because billet can be folded during transportation, transportation cost is low.4 Due to curves along the height direction, so with good ability against high pressure.5 02 box is the flat carton, commonly die cutting with few leftover material, cardboard utilization rate is high, when sealing, without seam, so the application is widespread.6 Hexagonal design.Packaging carton design application:1 Excellent machinability: generally, according to the particular requirements of built-in objects, very convenient for cutting, notching, such processing.2 Easy to use, is advantageous to the container packing, can save cost of logistics and sales.3 Hard and soft can be very protective: good against high pressure and buffer performance of the corrugated carton, after special processing can be moisture-proof, anti-static, preservation, and so on.4 For promotion: E type, F type and other fine corrugated products, was a large number of alternatives to traditional cardboard paper box, become the sales packaging to be bestowed favor on newly and silent salesman.5 Low cost.:almost 80% corrugated packaging products cost is determined by the cost of paper. Corrugated carton paper packaging cost is the lowest, generally, can be folded during transportation and storage, overall logistics cost is low.Abnormal packaging design.1 Bright colors, good quality , beautiful picture.2 Packaging structure is usually changed on the basis of the traditional structure, make special shapes.3 Abnormal box packaging design is aim to selling consumers surprises and imaginations.4 Generally, used for packing objects with special shapes.
